高邊開關是模擬電路和強勁的負載/輸出驅動器的經濟高效的集成.此類系統封裝器件的設 計為嚴格的汽車應用帶來了強勁的高電流負載控制.高邊開關的設計能夠提高主板空間的效率,節約系統的成本,他們于微控制器在一起為各種負載如馬達,照明,傳動器等等提供必要的保護和控制.
類比半導體在高端信號類產品和數?；旌袭a(chǎn)品上已經取得顯著成就，并在新能源、醫療、通訊等領域占據了一席之地。包括模擬前端、線性產品、智能驅動、電源管理、數據轉換器、音視頻等在內的全面產品線，并已有超過400多種型號的產品量產，品質贏得了業界的廣泛認可。
| 型號 |
通道數 |
25°C導通電阻 |
125°C導通電阻 |
典型負載電流 |
待機電流 |
控制接口 |
短路保護電流 |
電流鏡比例 |
工作溫度 |
封裝 |
等級 |
竟品 |
PDF下載 |
| HD70152QASSOP16P |
2 |
14.5 |
24.7 |
5 |
0.1 |
Hardware |
40 |
2950 |
-40-125 |
SSOP16PP |
Auto |
VND7E025,VND7020,VND9016 |
暫無 |
| HD70152QASSOP14P |
2 |
14.5 |
24.7 |
5 |
0.1 |
Hardware |
40 |
3700 |
-40-125 |
SSOP14PP |
Auto |
BTS7020-2,BTS7030-2 |
暫無 |
| HD70202QASSOP16P |
2 |
20 |
33 |
4.5 |
0.1 |
Hardware |
30 |
2800 |
-40-125 |
SSOP16PP |
Auto |
VND9025,VND7030 |
暫無 |
| HD70202QASSOP14P |
2 |
20 |
33 |
4.5 |
0.1 |
Hardware |
30 |
2800 |
-40-125 |
SSOP14PP |
Auto |
BTS7040-2 |
暫無 |
| HD70402QASSOP16P |
2 |
35 |
65 |
3 |
0.1 |
Hardware |
20 |
1340 |
-40-125 |
SSOP16PP |
Auto |
VND7E050,VND7050,VND7E040,VND7040 |
暫無 |
| HD70402QASSOP14P |
2 |
36 |
65 |
3 |
0.1 |
Hardware |
20 |
1340 |
-40-125 |
SSOP14PP |
Auto |
BTS7080-2,BTS7050-2 |
暫無 |
| HD70802QASSOP16P |
2 |
40 |
80 |
2 |
0.1 |
Hardware |
15 |
1200 |
-40-125 |
SSOP16PP |
Auto |
VND7140 |
暫無 |
| HD70802QASSOP14P |
2 |
40 |
80 |
2 |
0.1 |
Hardware |
15 |
1200 |
-40-125 |
SSOP14PP |
Auto |
BTS7200-2,BTS7120-2 |
暫無 |
| HD7008QASSOP16P |
1 |
6.2 |
9.5 |
11 |
0.1 |
Hardware |
70 |
5900 |
-40-125 |
SSOP16PP |
Auto |
VN7008,VN9008 |
暫無 |
| HD7008QASSOP14P |
1 |
8.2 |
12 |
10 |
0.1 |
Hardware |
60 |
5450 |
-40-125 |
SSOP14PP |
Auto |
BTS7008-lepa |
暫無 |
| HD7008MQASSOP16P |
1 |
6.2 |
9.5 |
11 |
0.1 |
Hardware |
70 |
5900 |
-40-125 |
SSOP16PP |
Auto |
VN7010,VN7016 |
暫無 |
| HD7008PQASSOP14P |
1 |
6.4 |
9.7 |
11 |
0.1 |
Hardware |
70 |
5450 |
-40-125 |
SSOP14PP |
Auto |
BTS700B-1EPP |
暫無 |
| HD7015QASSOP16P |
1 |
15 |
25 |
5 |
0.1 |
Hardware |
40 |
2950 |
-40-125 |
SSOP16PP |
Auto |
/ |
暫無 |
| HD7015QASSOP14P |
1 |
17.2 |
25 |
5 |
0.1 |
Hardware |
40 |
2800 |
-40-125 |
SSOP14PP |
Auto |
/ |
暫無 |
| HD7040MQASSOP16P |
1 |
35 |
TBD |
4 |
0.1 |
Hardware |
20 |
1340 |
-40-125 |
SSOP16PP |
Auto |
VN7040,VN7050 |
暫無 |
| HD7080MQASSOP16P |
1 |
35 |
TBD |
2.8 |
0.1 |
Hardware |
15 |
1200 |
-40-125 |
5S0P16PP |
Auto |
VN7140 |
暫無 |
